DAFoam: DAUtility Class Reference

Discrete Adjoint with OpenFOAM

Public Member Functions
	DAUtility ()
	Constructors. More...

virtual	~DAUtility ()
	Destructor. More...

Static Public Member Functions
static void	pyDict2OFDict (PyObject *pyDict, dictionary &ofDict)
	convert a python dictionary object to OpenFoam dictionary More...

template<class classType >
static label	listDeleteVal (List< classType > &listIn, const classType valDel)
	delete a value in the list More...

static void	writeMatrixBinary (const Mat matIn, const word prefix)
	write petsc matrix in binary format More...

static void	writeMatrixASCII (const Mat matIn, const word prefix)
	write petsc matrix in ascii format More...

static void	readMatrixBinary (Mat matIn, const word prefix)
	read petsc matrix in binary format More...

static void	writeVectorASCII (const Vec vecIn, const word prefix)
	write petsc vector in ascii format More...

static void	readVectorBinary (Vec vecIn, const word prefix)
	read petsc vector in binary format More...

static void	writeVectorBinary (const Vec vecIn, const word prefix)
	write petsc vector in binary format More...

static void	boundVar (const dictionary &allOptions, volScalarField &var, const label printToScreen)
	bound a volScalar variable based on parametes defined in DAOption::allOptions_ More...

static void	boundVar (const dictionary &allOptions, volVectorField &var, const label printToScreen)
	bound a volVector variable based on parametes defined in DAOption::allOptions_ More...

static label	isValueCloseToRef (const scalar val, const scalar refVal, const scalar tol=1.0e-6)
	check whether a value is close to a reference value by a tolerance More...

static globalIndex	genGlobalIndex (const label localIndexSize)
	generate global index numbering for local-global index transferring More...

static void	primalResidualControl (const SolverPerformance< scalar > &solverP, const label printToScreen, const word varName, scalar &primalMaxRes)
	control when to print the residual and also compute the maxInitRes More...

static void	primalResidualControl (const SolverPerformance< vector > &solverP, const label printToScreen, const word varName, scalar &primalMaxRes)
	control when to print the residual and also compute the maxInitRes More...

static label	myFindCell (const primitiveMesh &mesh, const point &point)

static label	isFieldReadable (const fvMesh &mesh, const word fieldName, const word fieldType)

template<class classType >
static void	swapLists (List< classType > &a, List< classType > &b)
	swap two lists More...

Static Public Attributes
static scalar	angleOfAttackRadForwardAD = -9999.0
	angle of attack in radian used in forward mode AD More...

static void *	pyCalcBeta = NULL
	define a function pointer template for Python call back More...

static pyComputeInterface	pyCalcBetaInterface = NULL

static void *	pyCalcBetaJacVecProd = NULL

static pyJacVecProdInterface	pyCalcBetaJacVecProdInterface = NULL

static void *	pySetModelName = NULL

static pySetCharInterface	pySetModelNameInterface = NULL

Detailed Description

Definition at line 34 of file DAUtility.H.

Constructor & Destructor Documentation

◆ DAUtility()

DAUtility ( )

Constructors.

Definition at line 16 of file DAUtility.C.

◆ ~DAUtility()

~DAUtility ( )

virtual

Destructor.

Definition at line 20 of file DAUtility.C.

Member Function Documentation

◆ pyDict2OFDict()

void pyDict2OFDict	(	PyObject *	pyDict,
		dictionary &	ofDict
	)

static

convert a python dictionary object to OpenFoam dictionary

Definition at line 24 of file DAUtility.C.

References k.

Referenced by DAOption::DAOption(), DASolver::New(), UnitTests::runDAUtilityTest1(), and DAOption::updateDAOption().

Here is the caller graph for this function:

◆ listDeleteVal()

label listDeleteVal	(	List< classType > &	listIn,
		const classType	valDel
	)

static

delete a value in the list

Definition at line 155 of file DAUtility.H.

References forAll().

Here is the call graph for this function:

◆ writeMatrixBinary()

void writeMatrixBinary	(	const Mat	matIn,
		const word	prefix
	)

static

write petsc matrix in binary format

Definition at line 411 of file DAUtility.C.

Referenced by DASolver::calcdRdWT(), DAJacCon::initializeStateBoundaryCon(), UnitTests::runDAUtilityTest1(), DAJacCon::setupdRdWCon(), and DASolver::writeMatrixBinary().

Here is the caller graph for this function:

◆ writeMatrixASCII()

void writeMatrixASCII	(	const Mat	matIn,
		const word	prefix
	)

static

write petsc matrix in ascii format

Definition at line 443 of file DAUtility.C.

Referenced by UnitTests::runDAUtilityTest1(), and DASolver::writeMatrixASCII().

Here is the caller graph for this function:

◆ readMatrixBinary()

void readMatrixBinary	(	Mat	matIn,
		const word	prefix
	)

static

read petsc matrix in binary format

Definition at line 378 of file DAUtility.C.

Referenced by DASolver::readMatrixBinary(), and UnitTests::runDAUtilityTest1().

Here is the caller graph for this function:

◆ writeVectorASCII()

void writeVectorASCII	(	const Vec	vecIn,
		const word	prefix
	)

static

write petsc vector in ascii format

Definition at line 347 of file DAUtility.C.

Referenced by DAJacCon::checkSpecialBCs(), UnitTests::runDAUtilityTest1(), DAJacCon::setupdRdWCon(), and DASolver::writeVectorASCII().

Here is the caller graph for this function:

◆ readVectorBinary()

void readVectorBinary	(	Vec	vecIn,
		const word	prefix
	)

static

read petsc vector in binary format

Definition at line 282 of file DAUtility.C.

Referenced by DAJacCon::readJacConColoring(), DASolver::readVectorBinary(), and UnitTests::runDAUtilityTest1().

Here is the caller graph for this function:

◆ writeVectorBinary()

void writeVectorBinary	(	const Vec	vecIn,
		const word	prefix
	)

static

write petsc vector in binary format

Definition at line 315 of file DAUtility.C.

Referenced by DAJacCon::calcJacConColoring(), UnitTests::runDAUtilityTest1(), and DASolver::writeVectorBinary().

Here is the caller graph for this function:

◆ boundVar() [1/2]

void boundVar	(	const dictionary &	allOptions,
		volScalarField &	var,
		const label	printToScreen
	)

static

bound a volScalar variable based on parametes defined in DAOption::allOptions_

Definition at line 475 of file DAUtility.C.

References allOptions, and forAll().

Referenced by DASpalartAllmaras::calcResiduals(), DAkOmega::calcResiduals(), DAkEpsilon::calcResiduals(), DASpalartAllmarasFv3::calcResiduals(), DAkOmegaSST::calcResiduals(), and DAkOmegaSSTLM::calcResiduals().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ boundVar() [2/2]

void boundVar	(	const dictionary &	allOptions,
		volVectorField &	var,
		const label	printToScreen
	)

static

bound a volVector variable based on parametes defined in DAOption::allOptions_

Definition at line 562 of file DAUtility.C.

References allOptions, and forAll().

Here is the call graph for this function:

◆ isValueCloseToRef()

label isValueCloseToRef	(	const scalar	val,
		const scalar	refVal,
		const scalar	tol = `1.0e-6`
	)

static

check whether a value is close to a reference value by a tolerance

Definition at line 707 of file DAUtility.C.

Referenced by DAJacCon::addPhi4PIV(), DAJacCon::allocateJacobianConnections(), DAJacCon::calcColoredColumns(), DAColoring::parallelD2Coloring(), DAJacCon::setupStateBoundaryConID(), and DAColoring::validateColoring().

Here is the caller graph for this function:

◆ genGlobalIndex()

globalIndex genGlobalIndex ( const label localIndexSize )

static

generate global index numbering for local-global index transferring

Definition at line 655 of file DAUtility.C.

◆ primalResidualControl() [1/2]

void primalResidualControl	(	const SolverPerformance< scalar > &	solverP,
		const label	printToScreen,
		const word	varName,
		scalar &	primalMaxRes
	)

static

control when to print the residual and also compute the maxInitRes

Definition at line 734 of file DAUtility.C.

Referenced by DASpalartAllmaras::calcResiduals(), DAkOmega::calcResiduals(), DAkEpsilon::calcResiduals(), DASpalartAllmarasFv3::calcResiduals(), DAkOmegaSST::calcResiduals(), DAkOmegaSSTLM::calcResiduals(), DAHeatTransferFoam::solvePrimal(), and DASolidDisplacementFoam::solvePrimal().

Here is the caller graph for this function:

◆ primalResidualControl() [2/2]

void primalResidualControl	(	const SolverPerformance< vector > &	solverP,
		const label	printToScreen,
		const word	varName,
		scalar &	primalMaxRes
	)

static

control when to print the residual and also compute the maxInitRes

Definition at line 762 of file DAUtility.C.

◆ myFindCell()

label myFindCell	(	const primitiveMesh &	mesh,
		const point &	point
	)

static

Definition at line 803 of file DAUtility.C.

References mesh.

Referenced by DAFunctionLocation::DAFunctionLocation(), DAFunctionVariance::DAFunctionVariance(), and DAFvSourceHeatSource::DAFvSourceHeatSource().

Here is the caller graph for this function:

◆ isFieldReadable()

label isFieldReadable	(	const fvMesh &	mesh,
		const word	fieldName,
		const word	fieldType
	)

static

Definition at line 817 of file DAUtility.C.

References mesh.

Referenced by DAPimpleDyMFoam::DAPimpleDyMFoam(), DAPimpleFoam::DAPimpleFoam(), DAResidualPimpleDyMFoam::DAResidualPimpleDyMFoam(), DAResidualPimpleFoam::DAResidualPimpleFoam(), DAResidualSimpleFoam::DAResidualSimpleFoam(), DASimpleFoam::DASimpleFoam(), DAStateInfoPimpleDyMFoam::DAStateInfoPimpleDyMFoam(), DAStateInfoPimpleFoam::DAStateInfoPimpleFoam(), and DAStateInfoSimpleFoam::DAStateInfoSimpleFoam().

Here is the caller graph for this function:

◆ swapLists()

void swapLists	(	List< classType > &	a,
		List< classType > &	b
	)

static

swap two lists

Definition at line 204 of file DAUtility.H.

Referenced by DAPimpleFoam::solveAdjointFP().

Here is the caller graph for this function:

Member Data Documentation

◆ angleOfAttackRadForwardAD

scalar angleOfAttackRadForwardAD = -9999.0

static

angle of attack in radian used in forward mode AD

Definition at line 114 of file DAUtility.H.

◆ pyCalcBeta

void * pyCalcBeta = NULL

static

define a function pointer template for Python call back

Definition at line 117 of file DAUtility.H.

Referenced by DARegression::compute(), and DASolver::initTensorFlowFuncs().

◆ pyCalcBetaInterface

pyComputeInterface pyCalcBetaInterface = NULL

static

Definition at line 118 of file DAUtility.H.

Referenced by DARegression::compute(), and DASolver::initTensorFlowFuncs().

◆ pyCalcBetaJacVecProd

void * pyCalcBetaJacVecProd = NULL

static

Definition at line 120 of file DAUtility.H.

Referenced by DASolver::initTensorFlowFuncs().

◆ pyCalcBetaJacVecProdInterface

pyJacVecProdInterface pyCalcBetaJacVecProdInterface = NULL

static

Definition at line 121 of file DAUtility.H.

Referenced by DASolver::initTensorFlowFuncs().

◆ pySetModelName

void * pySetModelName = NULL

static

Definition at line 123 of file DAUtility.H.

Referenced by DARegression::compute(), and DASolver::initTensorFlowFuncs().

◆ pySetModelNameInterface

pySetCharInterface pySetModelNameInterface = NULL

static

Definition at line 124 of file DAUtility.H.

Referenced by DARegression::compute(), and DASolver::initTensorFlowFuncs().

The documentation for this class was generated from the following files:

dafoam/src/adjoint/DAUtility/DAUtility.H
dafoam/src/adjoint/DASolver/DASolver.C
dafoam/src/adjoint/DAUtility/DAUtility.C
dafoam/src/pyUnitTests/UnitTests.C
